Airfiltronix G-50 Fume Containment Hood

The Airfiltronix G-50 Fume Containment Hood are designed to enclose materials and operations under negative pressure, thereby preventing airborne contaminants from escaping into the work environment. Contaminated air is drawn through a variety of filters to remove pollutants. Filters are available for both vapors and particulates and they can be combined for multiple substance filtration.

The hoods are constructed of clear, 1/4″ thick, acrylic panels with sturdy aluminum framing (other panel materials are available if required). They come equipped with a clear vinyl curtain providing easy access while maintaining optimal airflow across the opening (optional door and sash configurations are available upon request).

Blower/Filter modules are normally mounted on top of the hood, however, if space is limited they can be remotely located and connected to the hood via PVC hose. A high efficiency, brushless AC motor with dynamically balanced backward curved impeller moves up to 530 cfm in free air at a noise level of less than 68 db. Alternatively, a venting adapter kit is available for the blower to provide for both filtering and outside venting.



    • No outside venting required


    • Custom designs at affordable prices


    • Portable tabletop design


    • Variable blower speed control optimizes air flow efficiency


    • Full range of filters



Power Requirements: 115V, 50/60 Hz, 100W

Blower: 530 CFM (fee air), Backward Curved Impellor

Noise level: weighted noise level 68 dB max at 1 meter

Please Note:

1 If required the hood can be purchased without blower and filter units for connection to an existing venting system. Alternatively, a venting adapter kit is available for the blower to provide for both filtering and outside venting.

2 This unit can be manufactured in many different sizes and/or configurations. Please contact us to discuss your application or send us your specifications.

3 The units are supplied without filters. Selection of filters is dependent upon application.

Additional information




Fume Containment Hoods



Dimensions (W x D x H)

Workspace: 48"w x 17"d x 17"h Overall: 50"w x 18"d x 32.5"h


98 lbs
