Sakura Accu-Cut SRM 200 Microtome

Description

Sakura Accu-Cut SRM™ 200 Microtome

The Sakura Accu-Cut SRM™ 200 Microtome is a state-of-the-art instrument designed for the precise and accurate sectioning of biological specimens in histology and pathology laboratories. It is equipped with advanced technology and features that make it easy to use and maintain, and is capable of producing high-quality sections at a high speed.

The microtome has a compact design and is lightweight, making it easy to handle and transport. It is equipped with a user-friendly interface and a large touch screen display that allows users to easily view and control the sectioning process. The microtome also has a range of cutting modes and settings that can be programmed and stored for easy access, including serial sectioning, free-style sectioning, and cryosectioning.

One of the standout features of the Sakura Accu-Cut SRM™ 200 Microtome is its advanced blade technology. The microtome is equipped with a precision blade holder that holds the blade at a consistent angle, ensuring that the sections are consistently thin and precise. The blade holder is also adjustable, allowing users to fine-tune the blade angle to suit the specific needs of their application.

In addition to its advanced technology, the Sakura Accu-Cut SRM™ 200 Microtome is also highly efficient and reliable. It is capable of producing precise and accurate sections at a high speed, helping to streamline the workflow in histology and pathology laboratories. The microtome is also easy to maintain, with a self-diagnostic system that alerts users to any issues or maintenance needs.

The Sakura Accu-Cut SRM™ 200 Microtome is a versatile tool that is well-suited for use in a wide range of applications. It is suitable for use in hospitals, research labs, and commercial laboratories, and is capable of handling a variety of specimens, including tissues, cells, and other biological materials.

Overall, the Sakura Accu-Cut SRM™ 200 Microtome is a reliable and efficient instrument that is designed with advanced technology and user-friendly features to make it easy to use and maintain. It is an essential tool for histology and pathology laboratories, and is capable of producing precise and accurate sections at a high speed.

Specifications:
Dimensions 15.7″W x 18.5″D x 11.6″H (40.0 x 47.0 x 29.5 cm)
Working height 10.5 cm
Weight 64 lbs (29 kg)
Section Thickness Range 0.5 – 60 µm
Increment 0 – 2 µm (0.5 µm increments)
2 – 10 µm (1µm increments)
10 – 20 µm (2 µm increments)
20 – 60 µm (5 µm increments)
Coarse Feed Advance – Clockwise
Horizontal Specimen Advance 25 mm
Vertical Specimen Stroke Length 59 mm
Specimen Retraction 220 µm
Clearance Angle for Blade Holder 0 -10°
Three-axis Orientation
Horizontal: 8°
Vertical: 8°
Rotation: 90°
Micron Thickness Setting: Adjustable with visual display
Trimming Steps: 10 µm, 50 µm
Displacement of Blade Holder Base
North/South Maximum: 55 mm (Vertically)
With all adapters attached: 40 mm
East/West: 45 mm (Horizontally)

Professionally Refurbished by Rankin Biomedical
